A solenoid valve is an actuator used in industrial process automation control systems. It automatically opens or closes the valve after receiving an electronic control signal to control the flow of fluid medium in the pipeline. This allows for automatic adjustment or remote control of temperature, flow, pressure, and other parameters in the system.
The steam wire solenoid valve has a wide range of applications in various industries such as textile, printing and dyeing, chemical, plastic, rubber, pharmaceutical, food, building materials, machinery, electrical appliances, surface treatment, and scientific research departments. It is also commonly used in daily living facilities such as bathrooms, canteens, and air conditioning.
Brass,CF8
| Model NO. | 2W-06K | 2W-08K | 2W-160-10K | 2W-15K | 2W-20K | 2W-25K | 2W-32K | 2W-40K | 2W-50K |
| Pipe Size | 1/8" | 1/4" | 3/8" | 1/2" | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" |
| orifice size | 2.5mm | 4mm | 16mm | 16mm | 20mm | 25mm | 32mm | 40mm | 50mm |
| fluid medium | Air water oil,the neutral gas/liquid | service voltage | AC110V/220V/DC24V（50/60Hz) | ||||||
| operating type | polit type | type | Normally Open | ||||||
| Body Material | Brass | working pressure | (water, air): 1~10kgf/cm' | ||||||
| Material of sealing | Standard: below 80℃ fluid temperature use NBR / below 150℃ use VITON | ||||||||
| Model NO. | 2W-040-10 | 2W-160-10 | 2W-160-15 | 2W-200-20 | 2W-250-25 | 2W-320-32 | 2W-400-40 | 2W-500-50 | |
| Pipe Size | 3/8" | 1/2" | 3/4" | 1" | 1 1/4" | 11/2" | 2" | ||
| orifice size | 4mm | 16mm | 1 6mm | 20mm | 25mm | 32mm | 40mm | 50mm | |
| cv valle | 0.6 | 4.8 | 4.8 | 7.6 | 12 | 24 | 29 | 48 | |
| fluid medium | Air water oil,the neutral gas/liquid | ||||||||
| service voltage | AC380V AC220V AC110V AC24V DC24V DC12V (allow) ±10% | ||||||||
| operating type | direct acting | type | Normally Closed | ||||||
| Body Material | Brass | fluid viscosity | <20CST | ||||||
| working pressure | water,air:0~ 10kgf/cm' oil:0~ 7kgf/cm" | ||||||||
| Material of sealing | standard: below 80℃fluid temperature use NBR / below 120℃ use EPDM / below 150℃ use VITON | ||||||||
