The joint has the friction resistance of plastic medium and small size, making it an ideal material for completely oil-free wetting. When the PTFE soft connection is affected by the external temperature, the rubber protection wax in the PTFE soft connection is also affected by the external temperature and migrates to the surface of the PTFE soft connection (the migration process is from low temperature to high temperature, from low carbon to high carbon).
Edge performance: will not be harmed by the natural environment and working frequency, volume resistor up to 1018 mm cm, small dielectric loss, penetration, high packing pressure of four fluorine pall ring.
Used in strong acid and alkali, high temperature, strong corrosion of pipeline equipment, used in extreme environments, especially in the corrosive medium, including: transport of corrosive substances of the conveying pipe, exhaust steam pipe, steam pipe, rolling machine high-pressure oil pipe, aircraft hydraulic system and cold pressure system of high and low pressure pipeline, distillation tower, heat exchanger, kettle, tower, tank lining, gate valve and other chemical equipment.
| Nominal diameter | Length/mm | Axial displacement | Horizontal movement | Deflection angle | ||
| mm | inch | Compression | Extension | |||
| 32 | 1 1/4 | 95 | 6 | 9 | 9 | 15 |
| 40 | 1 1/2 | 95 | 6 | 10 | 9 | 15 |
| 50 | 2 | 105 | 7 | 10 | 10 | 15 |
| 65 | 2 1/2 | 115 | 7 | 13 | 11 | 15 |
| 80 | 3 | 135 | 8 | 15 | 12 | 15 |
| 100 | 4 | 150 | 10 | 19 | 13 | 15 |
| 125 | 5 | 165 | 12 | 19 | 13 | 15 |
| 150 | 6 | 180 | 12 | 20 | 14 | 15 |
| 200 | 8 | 210 | 16 | 25 | 22 | 15 |
| 250 | 10 | 230 | 16 | 25 | 22 | 15 |
| 300 | 12 | 245 | 16 | 25 | 22 | 15 |
| 350 | 14 | 255 | 16 | 25 | 22 | 15 |
| 400 | 16 | 255 | 16 | 25 | 22 | 15 |
| 450 | 18 | 255 | 16 | 25 | 22 | 15 |
| 500 | 20 | 255 | 16 | 25 | 22 | 15 |
| 600 | 24 | 260 | 16 | 25 | 22 | 15 |
